Double Ended Screw
1.DIN 939 Double-ended Bolts bm=1.5d
2.Source bolt manufacturer, own factory: with price advantage, eliminating the price difference of middlemen.
3.Adopt the industry's top high-quality thickened steel, high stability and long-lasting durability.
4.Support customer customization.
5.Professional sales and after-sales service, welcome to inquire at any time.
6.Delivery on time.
Double Ended Screw DIN939, also known as DIN939 stud bolts or thick-stem stud bolts, are high-strength fasteners widely used in mechanical engineering, construction, shipbuilding and other fields. According to the DIN939 standard, the dimensions and specifications of Double Ended Screw DIN939 are strictly standardized. This ensures that bolts produced by different manufacturers are interchangeable, which facilitates user selection and procurement. The shank of the DIN939 stud bolt is thicker, usually b1=1.25d (d is the nominal diameter of the thread). This design enhances its ability to withstand tensile and shear forces. DIN939 stud bolts can be processed and customized according to user needs, such as changing the length, thread specifications, etc., to meet the needs of different application scenarios.
Pictures
Product drawing
Product Specification
Size | M4 | M5 | M6 | M7 | M8 | M10 | M12 | M14 | M16 | M18 | M20 | M22 | M24 | M27 | M30 | M33 | M36 | M39 | M42 | M45 | M48 | M52 |
P | 0.7 | 0.8 | 1.0 | 1.0 | 1|1.25 | 1.25|1.5 | 1.25|1.5|1.75 | 1.5|2 | 2|3 | 2|3.5 | 3|4 | 3|4.5 | 3|5 | |||||||||
b1 | 5.0 | 6.5 | 7.5 | 9.0 | 10.0 | 12.0 | 15.0 | 18.0 | 20.0 | 22.0 | 25.0 | 28.0 | 30.0 | 35.0 | 38.0 | 42.0 | 45.0 | 50.0 | 52.0 | 58.0 | 60.0 | 65.0 |
ds max | 4.0 | 5.0 | 6.0 | 7.0 | 8.0 | 10.0 | 12.0 | 14.0 | 16.0 | 18.0 | 20.0 | 22.0 | 24.0 | 27.0 | 30.0 | 33.0 | 36.0 | 39.0 | 42.0 | 45.0 | 48.0 | 52.0 |
Some introduction about our company
Application
Jinan Star Company specializes in the production of fastener products. Our bolts, nuts and other products are widely used in machinery, railways, automobiles, construction, electrical, bridges, communications, firefighting and other industries.
Workshop
The workshop of Jinan Star Fastener Co., Ltd. is the core area of the company's production and manufacturing, with advanced production equipment. The reasonable layout of the workshop and the scientific production process ensure the efficient production and high-quality output of fastener products.
Testing Equipment
Jinan Star Fastener Company values product quality and has complete quality inspection equipment like tensile testing machines, torque testers, etc. These are used to test fastener products and evaluate mechanical properties, ensuring strict quality control from raw materials to finished products.
Exhibition
Jinan Star Fastener Company actively and enthusiastically participates in various exhibitions within the fastener industry. By taking part in these exhibitions, it is able to expand its extensive customer base. Through interacting with potential customers and industry insiders at these events, the company can establish new business connections and strengthen existing relationships. At these exhibitions, Jinan Star can gain in-depth insights into the latest technological advancements, market demands, and emerging trends. This continuous pursuit of improvement ensures that Jinan Star remains competitive and responsive to the dynamic market environment.
Packing
Service
1.We can produce bm=1.5d Double Ended Screw DIN939 in materials like steel and stainless steel. Inform our sales team of your needs and applicable scenarios. We'll answer questions about material impact on bolt performance.
2. If you're not sure which specifications are suitable, we'll provide a detailed specification sheet or selection guide to help you choose the right Double Ended Screw DIN939 according to your application needs.
3. We provide installation instructions or video tutorials to ensure correct installation.
